Proxera Documentation¶

Welcome to the official documentation for Proxera.

What is Proxera?¶

Proxera is a self-hosted reverse tunnel that lets HTTP services running in a private LAN be exposed to the internet — without opening any inbound firewall rules. It is similar in concept to Cloudflare Tunnel, but you remain in full control of where your traffic flows.

Early Alpha

This application is still in an early alpha and under active development. Breaking changes to the API may be introduced at any time until a v1 release.

How It Works¶

Component	Location	Repository
Proxera Server	Kubernetes / Cloud	This repository
Proxera Agent	LAN / on-premise	wenisch-tech/proxera-agent

Proxera Server runs in Kubernetes (or Docker). It receives public HTTP requests and dispatches them through a persistent WebSocket tunnel to the registered agent.
Proxera Agent runs in the LAN. It connects outbound to the server, awaits request frames, performs local HTTP calls, and streams the response back.

No inbound ports need to be opened in the LAN. All connectivity is agent-initiated.

Features¶

WebSocket reverse tunnel — persistent outbound connection from LAN agent to cloud server
Multi-domain routing — assign one or more public domains and optional path prefixes to any local service
Topology dashboard — interactive live graph showing pods, connected agents, and active routes
Live request logs — per-route scrolling access log streamed in real time
GitLab runner-style registration — admin creates a named agent slot and generates a one-time token
Horizontal scaling — optional Redis Pub/Sub message bus for multi-pod deployments; in-memory fallback for single-pod (no Redis required)
Admin UI + REST API — Bootstrap 5 admin panel and Swagger UI on port 8080
Prometheus metrics — exposed at /actuator/prometheus
Kubernetes Ingress management — create, edit, and delete Ingress resources directly from the Topology view when running in-cluster
Helm chart — production-ready Kubernetes deployment with RBAC, service account, and separate proxy/admin ingresses

Quick Start¶

Prerequisites¶

Before deploying, configure DNS records for your domains:

Domain	Target	Purpose
`app.intranet.example.com`	Proxera proxy ingress IP / CNAME	Public hostname for all routed services
`admin.proxera.example.com`	Proxera admin ingress IP / CNAME	Admin UI, REST API, and agent WebSocket tunnel

Wildcard DNS

Proxera supports dynamic Ingress creation directly from the Topology UI. To avoid adding a new DNS record for every service you expose, configure a wildcard entry *.intranet.example.com pointing to the proxy ingress IP / CNAME. Any subdomain you later create as an Ingress host will resolve automatically.

Step 1 — Deploy Proxera Server¶

Kubernetes (Helm):

helm repo add wenisch-tech https://charts.wenisch.tech
helm repo update
helm install proxera wenisch-tech/proxera \
  --set ingress.admin.enabled=true \
  --set ingress.admin.hosts[0].host=admin.proxera.example.com \
  -n proxera --create-namespace

Docker (local / dev):

docker run -d --name proxera -p 8080:8080 ghcr.io/wenisch-tech/proxera:latest

Proxera starts with an embedded H2 database by default — no external services required.

Step 2 — Log in to the Admin UI¶

Open https://admin.proxera.example.com/admin (or http://localhost:8080/admin for Docker).

Username	Password
`admin@proxera.local`	`admin`

Change default credentials

Create a new admin account and remove or change the default credentials immediately after first login via Admin → Users.

Step 3 — Create an Agent¶

An agent is a named slot that represents a Proxera Agent instance running in your LAN.

Via the Admin UI: Navigate to Agents → New Agent, enter a name (e.g. home-lab), and click Create.

Via the API:

curl -s -X POST http://localhost:8080/admin/api/agents \
  -H "X-API-KEY: your-api-key" \
  -H "Content-Type: application/json" \
  -d '{"name": "home-lab"}'

Step 4 — Generate a Registration Token¶

Each agent authenticates with a one-time registration token.

Copy immediately

The token is shown only once and cannot be retrieved later.

Via the Admin UI: Open the agent detail page and click Generate Token.

Via the API:

curl -s -X POST http://localhost:8080/admin/api/agents/<agent-id>/token \
  -H "X-API-KEY: your-api-key"

The response contains a token field — save it for the next step.

Step 5 — Install and Start the Agent¶

The Proxera Agent runs inside your LAN. Get it from wenisch-tech/proxera-agent.

Home Assistant Add-on:

Add the repository https://github.com/wenisch-tech/proxera-agent in Settings → Add-ons → Add-on Store → Repositories, then install Proxera Agent and set server_url and api_key in the Configuration tab. See the Home Assistant guide for full details.

Helm (Kubernetes in LAN):

helm repo add wenisch-tech https://charts.wenisch.tech
helm repo update
helm upgrade --install proxera-agent wenisch-tech/proxera-agent \
  --namespace proxera \
  --create-namespace \
  --set config.serverUrl="wss://admin.proxera.example.com/tunnel" \
  --set secret.apiKey="<registration-token>"

Docker:

docker run -d --name proxera-agent \
  -e PROXERA_SERVER_URL=wss://admin.proxera.example.com/tunnel \
  -e PROXERA_API_KEY=<registration-token> \
  ghcr.io/wenisch-tech/proxera-agent:latest

Binary — Linux:

curl -LO https://github.com/wenisch-tech/proxera-agent/releases/latest/download/proxera-agent-linux-amd64
chmod +x proxera-agent-linux-amd64
./proxera-agent-linux-amd64 \
  --server-url wss://admin.proxera.example.com/tunnel \
  --api-key "<registration-token>"

Binary — Windows (PowerShell):

Invoke-WebRequest -Uri "https://github.com/wenisch-tech/proxera-agent/releases/latest/download/proxera-agent-windows-amd64.exe" -OutFile "proxera-agent.exe"
.\proxera-agent.exe `
  --server-url wss://admin.proxera.example.com/tunnel `
  --api-key "<registration-token>"

Once started, the agent connects outbound to the server. Its status changes to Connected on the Agents page and in the Topology view. The registration token is consumed on first connect and cannot be reused.

Step 6 — Add Routes¶

A route maps a public domain (and optional path prefix) to a local service reachable by the agent.

Via the Admin UI: Navigate to Routes → New Route and fill in:

Field	Example	Description
Agent	`home-lab`	The agent that handles requests for this route
Domain	`myapp.proxy.example.com`	Public hostname that Proxera matches incoming requests against
Path prefix	`/`	URL path prefix to match (use `/` to match all paths)
Target URL	`http://192.168.1.10:3000`	The local service URL the agent forwards requests to

Via the API:

curl -s -X POST http://localhost:8080/admin/api/routes \
  -H "X-API-KEY: your-api-key" \
  -H "Content-Type: application/json" \
  -d '{
    "agentId": "<agent-id>",
    "domain": "myapp.proxy.example.com",
    "prefix": "/",
    "targetUrl": "http://192.168.1.10:3000"
  }'

You can add multiple routes per agent — each with a different domain or path prefix.

Step 7 — Create a Proxy Ingress (Kubernetes)¶

When running in Kubernetes, Proxera manages Kubernetes Ingress resources directly from the Topology view — no additional Helm values required. Click the + button in the INGRESS column to open the creation dialog.

Field	Example	Description
Name	`proxera-proxy`	Name of the Kubernetes Ingress resource
Class Name	`nginx`	Ingress class (e.g. `nginx`, `traefik`)
Annotations	`cert-manager.io/cluster-issuer: letsencrypt-prod`	Additional Ingress annotations
Host	`app.intranet.example.com`	Public hostname that routes to Proxera
Path	`/`	Path prefix (use `/` to match all traffic)
TLS	✓	Enable TLS and reference a cert-manager secret

Local / Docker

Ingress management is only available when running in-cluster. Outside Kubernetes, the topology shows an Ingress — Not available node.

Step 8 — Use It¶

With DNS already pointing app.intranet.example.com to the proxy ingress, the route is immediately reachable.

Any HTTP request to https://app.intranet.example.com is now:

Received by the Proxera Server
Matched against your routes by domain + path prefix
Forwarded through the WebSocket tunnel to the Proxera Agent in your LAN
Proxied by the agent to http://192.168.1.10:3000
The response is streamed back to the original client

Local Docker testing

Pass the host header explicitly when testing locally: curl -H "Host: myapp.proxy.example.com" http://localhost:8080

Monitor live traffic under Routes → (route name) → Logs or watch the Topology view for connected agents and in-flight requests.

Navigate the Docs¶

Architecture — System design, tunnel protocol, scaling model, data model
Configuration — Environment variables and Helm values reference
API Reference — REST API endpoints and examples
Home Assistant — Installing and configuring the Proxera Agent as a Home Assistant add-on

Project Links¶

Repository: https://github.com/wenisch-tech/proxera
Agent repository: https://github.com/wenisch-tech/proxera-agent
Container image: https://github.com/wenisch-tech/proxera/pkgs/container/proxera
Helm chart: https://charts.wenisch.tech
